Detail Information

Product Name:	Full Automatic Spray Type Continuous Pasteurizing And Cooling Machine	Model:	QHBS-X
Production Capacity:	100～1000 Cans/min	Sterilization Temperature:	90～100℃
Temperature After Sterilization:	Normal Temperature	Sterilization Mode:	Sterilization Mode
Cooling Mode:	Circuled Warm Water And Cooling Water	Steam Pressure:	0.4～0.6 MPa
Highlight:	Full Automatic Tunnel Pasteuriser , Tunnel Pasteuriser Spray Type , Continuous Sterilization And Cooling Machine

Product Description

PRODUCT NAME

Full Automatic Spray Type Continuous Pasteurizing and Cooling Machine

PRODUCT PARAMETER

Production capacity	100～1000 cans/min
Sterilization temperature	90～100℃
Temperature after sterilization	Normal temperature
Sterilization mode	Steam or mixed hot water spraying
Cooling mode	Circuled warm water and cooling water
Steam pressure	0.4～0.6 MPa

PRODUCT DESCRIPTION

Continuous spray type sterilization and cooling machine is innovatively designed and manufactured by Qihong Company. The products are sterilized and cooled by three processing stages such as steam spray or circulated hot water spray sterilization, circulated warm water precooling and chilled water spray cooling. The machines is equipped with following mechanisms as: stainless steel frame, imported Italian special high temperature resistant network chain, and stepless speed adjustment system. It’s applicable for the sterilization of such foodstuff as tomato ketchup, fruit and vegetable juice beverage, pickles, kraut, preserved szechuan pickle, potherb, jam, bean products, etc., packaged by such containers as metal cans, galss bottles, PET bottles, PET bags.

PRODUCT ADVANTAGE

1. High-efficiency sterilization: The spray sterilization and cooling machine adopts high-pressure spraying technology, which can evenly spray disinfectant on the surface of articles, thoroughly killing bacteria and viruses, and achieving high-efficiency sterilization.
2. Energy saving: The equipment adopts a closed-loop circulating water system, and reduces water resource waste by recycling cooling water, thereby saving energy and costs.
3. Extending the shelf life of goods: The spray sterilization and cooling machine can sterilize the goods while cooling them, thereby extending the shelf life of the goods and increasing their sales and use cycle.
4. Improving production efficiency: The equipment adopts the spray-type continuous production process, with stable operation and simple operation, greatly improving production efficiency and shortening the production cycle.
5. Widely applicable: The spray sterilization and cooling machine is suitable for the production process of various liquid foods, such as juice, beverages, dairy products, etc., and can meet the production needs of different types and capacities of food.

Full Automatic Tunnel Pasteurizer, Spray Type Continuous Pasteurizing And Cooling Machine 0

Tag:

Place of Origin:	CHINA
Brand Name:	QIHONG
Model Number:	QHBS-X

Minimum Order Quantity:	1 set
Price:	To be quoted when contacting with the supplier
Packaging Details:	Wrapping film packaging
Delivery Time:	Within 50 days since advance payment
Supply Ability:	1 set per month
